60°C Freezer

BDF-60V608 / BDF-60V708 / BDF-60V808 / BDF-60V938

Suitable for ultra-low temperature experiments in scientific research institutions, special materials, electronics industry, chemical industry, university experiments, biotechnology, offshore fishing, etc

Key features

Monitored temperature
Alarms and sample protection
Capacity matched to inventory

Made to orderPrice on request

Manufacturer: BIOBASE

Request a quote

Reply within 24 hoursValidated selection and configurationDelivery across mainland Portugal, Madeira, the Azores, and all European countries.

01 / Accessories

Available accessories

Included accessories

Test hole

Optional accessories

Temperature recorder

Final contents, accessory compatibility and availability are confirmed in the quotation for the selected model.

02 / LaboratoriX technical datasheet

LaboratoriX technical datasheet

Technical parameters consolidated from the manufacturer documentation. Each column corresponds to one model; shared values are clearly identified. Final configuration, accessories, power supply and applicable documentation are confirmed with the quotation.

Parameter	BDF-60V608	BDF-60V708	BDF-60V808	BDF-60V938
Capacity	608 L	708 L	808 L	938 L
Temp. Range	Common to all models-25~-60 °C
Temp. Accuracy	Common to all models0.1 °C
Temp. Uniformity	Common to all models±4 °C
Temp. Stability	Common to all models±4 °C
Control System	Common to all modelsMicroprocessor control
Display	Common to all modelsLED display
Alarm	Common to all modelsHigh / low temperature alarm, controller failure alarm
Refrigeration Type	Common to all modelsDirect-cooling
Refrigerant	R290/R170, 220 g	R290/R170, 240 g	R290/R170, 260 g	R290/R170, 270 g
Compressor	Common to all modelsInternational famous brand compressor/2(Dual independent refrigeration system)
Condenser&Evaporator	Common to all modelsCopper tube aluminum fin condenser; cabinet-wrapped copper tube evaporator
Defrost	Common to all modelsManual defrost
Construction	Common to all modelsPolyurethane cyclopentane foam
Material — Internal Material	Common to all models304 stainless steel
Material — External Material	Common to all modelsSprayed steel plate
Door	Common to all modelsOuter door: sprayed steel plate outer door1 Interior door: 304 stainless steel door4
Consumption	900 W	1050 W	1100 W	1100 W
Power Supply	Common to all modelsAC220V, 50 Hz(Standard); 110/220 V, 60 Hz(Optional)
Casters	Common to all modelsYes
Shelf	Common to all models3
Standard Accessory	Common to all modelsTest hole
Optional Accessory	Common to all modelsTemperature recorder
Internal Size(WDH)	750 × 715 × 1200 mm	890 × 715 × 1200 mm	850 × 725 × 1335 mm	1040 × 715 × 1320 mm
External Size(WDH)	990 × 1030 × 1860 mm	1130 × 1030 × 1860 mm	1090 × 1010 × 2000 mm	1280 × 1030 × 1980 mm
Package Size(WDH)	1120 × 1080 × 2010 mm	1280 × 1080 × 2150 mm	1280 × 1080 × 2150 mm	1410 × 1080 × 2130 mm
Net Weight	245 kg	285 kg	300 kg	320 kg
Gross Weight	288 kg	345 kg	370 kg	405 kg

MADE-TO-ORDER SUPPLY

Do you need this equipment?

Share the application, configuration, quantity and delivery location. We prepare a tailored proposal with the required documentation.
