Horizontal Laminar Flow Cabinet

BBS-H1300 / BBS-H1800

Laminar Flow Cabinet is used only for sample protection. Laminar Flow Cabinet is a work bench or similar enclosure, which creates a particle-free working environment by taking air through a filtration system and exhausting it across a work surface in a laminar or unidirectional air stream.

Key features

HEPA-filtered laminar airflow
Sample protection
Vertical or horizontal configuration

Made to orderPrice on request

Manufacturer: BIOBASE

Request a quote

Reply within 24 hoursValidated selection and configurationDelivery to the UK, all European countries, USA, Canada, Mexico and South America.

01 / Accessories

Available accessories

Included accessories

LED lamp
UV lamp*2
Base stand
Gas tap
Waterproof socket*2
Water tap(only for BBS-H1800)

Optional accessories

Electric height adjustable base stand

Final contents, accessory compatibility and availability are confirmed in the quotation for the selected model.

02 / LaboratoriX technical datasheet

LaboratoriX technical datasheet

Technical parameters consolidated from the manufacturer documentation. Each column corresponds to one model; shared values are clearly identified. Final configuration, accessories, power supply and applicable documentation are confirmed with the quotation.

Parameter	BBS-H1300	BBS-H1800
External Size(WDH)	1300 × 820 × 2040 mm	1800 × 820 × 2070 mm
Internal Size(WDH)	1200 × 500 × 570 mm	1700 × 500 × 570 mm
Work Surface Height	Common to all models750 mm
Display	Common to all modelsLCD display
Airflow Velocity	Common to all modelsAverage of 0.3–0.5m/s
Material	Common to all modelsMain Body: Cold-rolled steel with anti-bacteria powder coating
Material (2)	Common to all modelsWork Table: 304 stainless steel
Material (3)	Common to all modelsSide and Front Window: 5 mm toughened glass, anti-UV
Pre-filter	Common to all modelsPolyester fiber, washable
HEPA Filter	Common to all models99.995 % efficiency at 0.3 µm
Noise	Common to all models<65dB
Front Window	Common to all modelsMotorized
Max Opening	Common to all models430 mm
LED Lamp	*12 W1**	*16 W2**
UV Lamp	Common to all models30 W*1
UV Lamp (2)	Common to all modelsEmission of 253.7 nanometers
Consumption	400 W	500 W
Waterproof Socket	Common to all modelsTwo, total load≤500 W
Caster	Common to all modelsUniversal caster with leveling feet
Power Supply	Common to all modelsAC220V±10 %, 50/60 Hz; 110 V±10 %, 60 Hz
Standard Accessory	Common to all modelsLED lamp, UV lamp2, Base stand, Gas tap, Waterproof socket2, Water tap(only for BBS-H1800)
Optional Accessory	Common to all modelsElectric height adjustable base stand
Gross Weight	254 kg	328 kg
Package Size(WDH)	1450 × 1060 × 1650 mm	1950 × 1060 × 1600 mm
