Ductless Fume Hood

FH1000(C) / FH1200(C) / FH1500(C) / FH1800(C)

In chemical laboratories, a lot of odors, moisture and corrosive substances will be generated during the experiment. To protect the safety of users and prevent the spread of pollutants in laboratories, fume hoods are used.

Key features

Ducted or filtered vapour extraction
Operator protection
Materials suited to chemical agents

Made to orderPrice on request

Manufacturer: BIOBASE

Request a quote

Reply within 24 hoursValidated selection and configurationDelivery to the UK, all European countries, USA, Canada, Mexico and South America.

01 / Accessories

Available accessories

Included accessories

Fluorescent lamp
Base cabinet
Total load of 2 waterproof sockets: 500 W
Chemical filter

Optional accessories

Water tap
Gas tap
Water sink
Electric height
Adjustable base stand
HEPA filter
UV Lamp

Final contents, accessory compatibility and availability are confirmed in the quotation for the selected model.

02 / LaboratoriX technical datasheet

LaboratoriX technical datasheet

Technical parameters consolidated from the manufacturer documentation. Each column corresponds to one model; shared values are clearly identified. Final configuration, accessories, power supply and applicable documentation are confirmed with the quotation.

Parameter	FH1000(C)	FH1200(C)	FH1500(C)	FH1800(C)
External Size(WDH)	1000 × 830 × 2140 mm	1200 × 830 × 2140 mm	1500 × 940 × 2140 mm	1800 × 940 × 2140 mm
Internal Size(WDH)	910 × 690 × 740 mm	1110 × 690 × 740 mm	1410 × 690 × 740 mm	1710 × 690 × 740 mm
Work Surface Height	Common to all models900 mm
Max. Opening	Common to all models650 mm
Air Velocity	Common to all models0.4–0.6m/s
Airflow Volume	136m³/h	136m³/h	432m³/h	547m³/h
Noise	Common to all models≤58dB(A)
Fluorescent Lamp	*12 W2**	*12 W2**	*12 W3**	*12 W3**
UV Lamp(Optional)	Common to all modelsEmission of 253.7 nanometers for most efficient decontamination
Blower	Common to all modelsBuilt-in centrifugal blower, speed adjustable
Front Window	Common to all modelsAcrylic window, Manual, Reversal design
Power Supply	Common to all modelsAC220V±10 %, 50/60 Hz; 110 V±10 %, 60 Hz
Consumption	400 W	400 W	500 W	500 W
Material — Exterior	Common to all modelsCold-rolled steel with anti-bacteria powder coating
Material — Side Window	Common to all modelsAcrylic window
Material — Work Table	Common to all modelsChemical resistant phenolic resin
Chemical Filter	2pcs	2pcs	4pcs	4pcs
Optional Accessory	Common to all modelsWater tap, Gas tap, Water sink, Electric height, Adjustable base stand, HEPA Filter, UV Lamp
Gross Weight	163 kg; 86 kg	180 kg; 95 kg	249 kg; 115 kg	275 kg; 129 kg
Package Size — Main Body	1140 × 1040 × 1490 mm	1350 × 1040 × 1490 mm	1650 × 11 4 0 × 1490 mm	1950 × 11 4 0 × 1490 mm
Package Size — Base Cabinet	1140 × 1040 × 1060 mm	1350 × 1040 × 1060 mm	1650 × 11 4 0 × 1060 mm	1950 × 11 4 0 × 1060 mm

MADE-TO-ORDER SUPPLY

Do you need this equipment?

Share the application, configuration, quantity and delivery location. We prepare a tailored proposal with the required documentation.
