Laboratory analysis

Colorimeter

BCM-110 / BCM-200

The Colorimeter is a precise analytical instrument designed to measure the absorbance and transmittance of light through liquid samples, enabling accurate determination of concentration based on color intensity.

Key features

  • Digital measurement
  • Method matched to the parameter
  • Repeatable results and data capture
Made to orderPrice on request
Manufacturer
BIOBASE
Request a quote
Reply within 24 hoursValidated selection and configurationDelivery across mainland Portugal, Madeira, the Azores, and all European countries.

01 / Accessories

Available accessories

Optional accessories

  • Miniature thermal printer
  • Powder test box
  • Universal test components

Final contents, accessory compatibility and availability are confirmed in the quotation for the selected model.

02 / LaboratoriX technical datasheet

LaboratoriX technical datasheet

Technical parameters consolidated from the manufacturer documentation. Each column corresponds to one model; shared values are clearly identified. Final configuration, accessories, power supply and applicable documentation are confirmed with the quotation.

ParameterBCM-110BCM-200
Illuminating/Viewing Geometry
Common to all models8/d
Measuring Apertureφ4 mmφ8 mm
Detector
Common to all modelsSilicon photoelectric diode
Color Space
Common to all modelsCIEL*a*b*C*h* CIEL*a*b*CIEXYZ
Color Difference Formula
Common to all modelsΔE*ab ΔL*a*b ΔE*C*h
Light Source
Common to all modelsD65
Light Source Device
Common to all modelsLED blue light excitation
Display
Common to all modelsTFT LCD
Errors Between Each Equipment≤0.80ΔE*ab≤0.50ΔE*ab
Storage
Common to all models100pcs standards, 20000pcs samples
RepeatabilityStandard deviation within AE*ab 0.08 Average of 30 measurements of standard white plateStandard deviation within AE*ab 0.07 Average of 30 measurements of standard white plate
Lamp Life
Common to all models5 years, more than 1.6 million time
Charging Time
Common to all models8 hours-100 % electricity
Measurement Times Before Recharging
Common to all models3000 times in 8 hours
Ambient Temp./Humidity Range
Common to all models-10–40 °C, relative humidity 0–85 % without condensation
Data Interface
Common to all modelsUSB
Optional AccessoryMiniature thermal printer, powder test boxUniversal test components, powder test box, miniature thermal printer
Power Supply
Common to all modelsRechargeable li-ion battery 3.7 V@3200mAh
External Size(W*D*H)205 × 67 × 80 mm205 × 70 × 100 mm
Package Size(W*D*H)
Common to all models370 × 320 × 160 mm
Net Weight0.45 kg0.5 kg
Gross Weight
Common to all models4 kg

Technical data supplied by BIOBASE.
