Photography and technical data supplied by: BIOBASE · 1 image.

Laboratory analysis

Soil Compaction Meter

SCM-750-II

It is a professional device used to measure the compactness of soil. It assesses the physical properties of soil by detecting its ability to resist external force intrusion

Key features

  • Digital measurement
  • Method matched to the parameter
  • Repeatable results and data capture
Made to orderPrice on request
Manufacturer
BIOBASE
Request a quote
Reply within 24 hoursValidated selection and configurationDelivery across mainland Portugal, Madeira, the Azores, and all European countries.

01 / LaboratoriX technical datasheet

LaboratoriX technical datasheet

Technical parameters consolidated from the manufacturer documentation. Each column corresponds to one model; shared values are clearly identified. Final configuration, accessories, power supply and applicable documentation are confirmed with the quotation.

ParameterSCM-750-II
Function
General type, display soil compaction(KPa, kg/cm 2, N/cm 2)directly, with data saving function
Range
0–10,000KPa; 0–100 kg/cm 2; 0–1,000N/cm 2 (switchable)
Depth
0–375 mm(measuring rod is 400 mm)
Accuracy
±0.5‰ FS
Position Accuracy
Three decimal ±0.05(≤50m)
Storage Capacity
Almost up to 30,000 groups in handset, and equipped with 4G Micro SD
Data-Collection Interval
5 min~99hour
Working Power Supply
Battery: 8.4 V lithium battery Power Adapter: 100–240 V, 50/60 Hz
Working Current
Stand-by power consumption 10 mA, working power consumption according to the configuration
Package Size(L*W*H)
400 × 200 × 200 mm
Gross Weight
3 kg

Technical data supplied by BIOBASE.
